AT-Measure ST1


Automatic image dimension measurement system



Easy anyway! Just click
High accuracy automatic measurement is possible by using double-sided telecentric lens!
Easy all!Automatic image dimension measurement in the image with just click.


Model No.AT-Measure ST1
WeightAbout 7kg
AccessoryDouble-sided telecentric lens, 5 mega pixel USB3 Vision camera, parallel transmitted light, stand with level gauge, glass scale for calibration, automatic image dimension measurement software AT-Measure

PC is not included.
Please prepare a PC with the following specifications.
Operating environment
Supported OS:Windows 8, 8.1, 10(64bit)
CPU:Core-i3 or above
Memory:8GB or more
Working distance228mm
Depth of field34.8mm
Measurement accuracyWithin ± 0.1%
Number of camera pixels5 MP
